Square Wire
Mesh
The wires in this design of mesh are woven with a gap. This results in open apertures, which liquids can stream through. Exceptionally low resistance and particularly effective backwashing are two particular characteristics of this mesh. Square weave meshes are used for dirt filters with low pressure differentials, for applications such as backwashing in conjunction with support meshes.
Benefits:
The highest levels of quality can only be achieved when every aspect is right.
- High quality raw materials
- State of the art weaving machines and equipment
- Innovative mesh designs
- Decades of experience and well supported knowledge in development, production and application
- Consistent quality control
Quality Features
- Extremely high levels of weaving accuracy, regularity and definition
- High levels of stability and rigidity
- Above average thermal resistance and corrosion resistance
- Resistance to humidity and static loading
- Easy to fabricate, good flatness, no twist
- Exceptional performance compared to polyester meshes
- Regular retention of elasticity under tension
- Perfect reproducibility across the board
Selecting the correct mesh is your guarantee of economical filtration and separation, thanks to:
Increased accuracy
Long service life
High levels of efficiency
Reduced downtime
Excellent throughput
Improved economy
Square Mesh
There are several basic principles involved in choosing the right square mesh.
Aperture Size:
This determines the size of the particles to be eliminated. We offer as standard meshes from 16mm to 20 microns (0.020mm) compliant with ISO standard 4783. Where screening requires very tight tolerances, the manufacturing tolerances of the mesh must also be taken into consideration.
Wire Diameter:
Selecting the wire diameter involves a number of different considerations. The thicker the wire, the stronger and more robust the mesh. On the other hand, a thicker wire will reduce the open area and therefore reduce performance.
Reducing the wire diameter whilst maintaining the same aperture size increases the number of apertures within a defined surface area. Both performance and efficiency will increase.
Materials:
The most popular material is stainless steel to AISI 304 or AISI 316; selected specifications are also available in chrome steel to AISI 430.
Mesh Selection:
In many cases, the right specification can only be decided after carrying out trials. The open area is directly or indirectly influenced by the life of the screen.
If you have any suggestions or concerns, we are available to address them. Let us know how we can help you.
